Technical Parameter
| Model and Specifications | Rated Voltage/Frequency | Light Source | Power (W) | Luminous Flux (lm) | Connector | Corrosion Resistance Rating | Protection Rating |
|---|---|---|---|---|---|---|---|
| XQL9100S | 220V/50Hz | LED | 10~30 | 1000~3000 | Waterproof type | WF2 | IP66 |
| 20~45 | 2000~4500 |
Product Features
1. The housing is SMC compression molded, offering high strength, impact resistance, and corrosion resistance; the lens is polycarbonate injection molded, featuring high light transmission and superior impact resistance;
2. The luminaire employs a curved sealing structure, providing excellent waterproof and dustproof performance;
3. The built-in ballast is a proprietary product with a power factor cosφ ≥ 0.85;
4. The built-in isolating switch automatically switches the power supply during startup, enhancing product safety;
5. Emergency devices can be configured per user requirements; when the emergency power source disconnects, the luminaire automatically switches to emergency lighting mode;
6. Supports both conduit and cable wiring methods.
Installation Dimensions
Applicable Scope
Applications
This product series is suitable for lighting in power plants, steel mills, petrochemical plants, ships, stadiums, parking lots, basements, and similar locations.
Operating Conditions
1. Ambient temperature: -25°C to 35°C;
2. Installation altitude not exceeding 2000 meters above sea level;
3. Corrosive environments such as strong acids, strong alkalis, salt spray, and chlorine gas, as well as humid, dusty, and water-prone environments;
