Technical Parameter
| Model and Specifications | Explosion-proof Marking | Light Source | Luminaire Type | Power (W) | Luminous Flux (lm) | Color Temperature (K) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| BED60-□ | Ex db IIC T6 Gb Ex tb IIIC T80°C Db | LED | I | 10~30 | 1200~3600 | 3000~5700 | 1.9 |
| II | 40~60 | 4800~7200 | 3.68 | ||||
| III | 70~100 | 8400~12000 | 4.75 | ||||
| Ex db IIC T5 Gb Ex tb IIIC T95°C Db | IV | 120~150 | 14400~18000 | 5.86 |
| Rated voltage | Inlet thread | Cable outer diameter | Degree of protection | Corrosion Resistance Rating |
|---|---|---|---|---|
| AC 220V, DC 36V, DC 24V | G3/4" | Φ10~Φ14mm | IP66 | WF1 WF2* |
| Emergency starting time (S) | Charging time (h) | Emergency power (W) | Light Source Power (W) | Emergency lighting time (min) |
|---|---|---|---|---|
| ≤0.3 | 24 | 50-20 | 10-30 | ≥60min、≥90min optional |
| 10-50 | 40-150 |
Product Features
1. Radiator designed with special die-cast aluminum alloy, featuring high-pressure electrostatic powder coating;
2. Exposed stainless steel fasteners with high corrosion resistance;
3. Flanged explosion-proof joint surface, pure explosion-proof structure for enhanced reliability;
4. Multi-point light emission with high luminous efficiency, delivering uniform illumination without glare;
5. Constant-current power supply with wide voltage input and constant-current output, featuring protection against shunt current, surge, overcurrent, open circuit, short circuit, high temperature, and electromagnetic interference;
6. Microwave-sensing dimming system for energy efficiency and environmental protection;
7. Power factor cosφ ≥ 0.95;
8. Compatible with modular emergency kits for automatic switchover to emergency lighting during power outages;
9. Suitable for conduit or cable wiring.
Installation Dimensions
| Serial No | Specification and model | Type of lamp housing | Power range (W) | Φ(mm) | h(mm) | A(mm) |
|---|---|---|---|---|---|---|
| 1 | BED60-30W | I | 10-30 | 181 | 145 | 80 |
| 2 | BED60-60W | II | 40-60 | 225 | 161 | 95 |
| 3 | BED60-100W | III | 70-100 | 254 | 175 | 95 |
| 4 | BED60-150W | IV | 120-150 | 291 | 180 | 120 |
Applicable Scope
1. Suitable for Zone 1 and Zone 2 locations in explosive gas environments;
2. Suitable for Class IIA, IIB, and IIC explosive gas environments;
3. Suitable for Zone 21 and Zone 22 locations in explosive dust environments;
4. Suitable for Class IIIA, IIIB, and IIC explosive dust environments;
5. Suitable for temperature classes T1 to T6;
6. Suitable for energy-saving retrofit projects and locations where maintenance or replacement is difficult;
7. Widely used for lighting in petroleum extraction, refining, chemical processing, military manufacturing, textile production, food processing, offshore oil platforms, oil tankers, and similar applications.
